ماژول کنترلر دما با نمایشگر W1401 12V/10A

W1401 DC 12V Intelligent Digital Temperature Controller Module
Description
Imported high-speed microcontroller, precise Intelligent Control
Three window display at a glance
Setting is simple, easy to operate
Wide Range -9 ~ 99 ℃ arbitrarily set
Space for a variety of temperature control, temperature control, incubators, etc.
Feature:
Temperature range: -9-99 ℃
Accuracy: 1 ℃
Control accuracy: 1 ℃
Setting Range: -9-99 ℃
Refresh rate: 0.5S
Input Power: DC12V
Output: relay output, capacity 220V 10A / 12V 10A
Environmental requirements: -10-60 centigrade
Humidity: 20% -85%
Temperature sensor: NTC(3950-10k 1%)
Usage:
Connect the power supply and equipment to the controller power is displayed as a measure
temperature, set up according to their needs STAR or STOP, the thermostat 10A relay
outputs to meet a variety of high-power loads, connect the control circuit, for the thermostat to power
Start indicator, LED and buzzer status description:
Start indicator: START (red) indicator light, said the relay is closed, the machine starts to work
Stop lights: STOP (green) light is on, the relay is lost, the device stops working
Digital tube: middle red LED display for the current temperature detected Green LED on the left to set the start temperature Right side of the green LED is set to stop temperature
Key:
START “▲ ▼” to set the starting temperature
STOP “▲ ▼” set the stop temperature
Hot start – cooling mode
When setting the start temperature value> stop temperature, when the detected
temperature ≥ start temperature, the relay is closed, refrigeration equipment work; when the
detected temperature ≤ stop temperature, the relay off, refrigeration equipment stops
working. For example: Set the start temperature is 30 ℃, stop temperature is 25 ℃, when
the detected temperature ≥30 ℃, the relay is closed, start indicator (red) light; when the
detected temperature ≤25 ℃, the relay off, stop instruction light (green) light.
Cold start – heating mode
When setting the start temperature
