MAX6675 Module+K Type Thermocouple Sensor Measure
The MAX6675 performs cold-junction compensation and digitizes the signal from a type-K thermocouple. The data is output in a 12-bit resolution, SPI-compatible, read-only format. This MAX6675 Module + K Type Thermocouple Sensor Measure 1024°C Temperature sensor makes use of the Maxim MAX6675 K-Thermocouple to digital converter IC to provide a microcontroller compatible digital serial interface (SPI compatible) for giving an accurate temperature-compensated measurement of the supplied K-Type thermocouple sensor.
Features
• Model: MAX6675
• Operating Voltage: 3.3~5.5VDC
• Temperature Range: 0 to +1024°C
• Cold Junction Compensation Range: -20 to +80°C
• Resolution: 0.25°C
• Internal integrated cold junction compensation circuit;
• Temperature signal can be converted into 12-bit digital
• Embedded thermocouple break detection circuitry.
• K-type temperature probe
• Simple SPI serial output temperature.
• High impedance differential inputs.
• Thermocouple break detection.
• 2000V of ESD signal.
